THE quint-it WALL qi1.
The quint-it wall system is an innovative full glass system in which vertical posts are not needed. Clearness and understatement are fortified through the anthracite grey colored glass panels. The patented products are an expression of a responsible, environmental handling with high-quality materials and innovative techniques. The profiles in the revolving- and sliding doors are the same size as the profiles in the frames and they are flush to all glass surfaces. They have been developed according to the principle of the golden ratio.
|_ Glass: clear, opaque
|_ Doors: normal door height, full room height
|_ Revolving door, sliding door
|_ Sustainable, environmental
|_ Electrical installations possible
|_ Wall organisation, communication, flexibility
The system adjusts to the design requirements from architecture and interior design and is a tool for the ideas of architects. Room acoustical solutions with individually printable surfaces offer an infinite diversity of variation opportunities.
|_ For industry, contract business, and private homes
|_ With barrier-free, handicap accessible full glass doors
|_ With anti-panic functions for safety technology relevant areas
|_ Acoustically effective surfaces, which can be integrated in the wall
|_ Prepared for E-bus systems on operation- and safety relevant areas
|_ Recyclable and without any PVC and softeners (basic material aluminum)
|_ Open and flexible office space with the new wall organisation qi5
THE quint-it WALL qi1 | DETAILS.
|_ Shock- and scratch-resistant, easy to maintain, powder coated anthracite grey aluminum profile
|_ 10 mm, 12 mm – 17,5 mm glass possible. Sound absorption with 16,76 mm VSG glass 42 dB in glass
|_ Height adjustment in the system +/- 9 mm
|_ Connections to wall, floor, ceiling, T-joint possible, inside and outside corners
|_ The profiles of the revolving- and sliding door are dimensionally co-ordinated
|_ All glass levels are flush to the surface: profiles, lock case, door frame, hinges, door closer
THE REVOLING DOOR FOR WALL qi1.
|_ Revolving door with a flush installed anthracite grey lock case
|_ Glass thickness for glass doors 10mm, 12mm - 17,5mm ESG / VSG
|_ The revolving door can as an option be placed in glass or in the wall
|_ Options: bar handle, door locker, magnetic hold, bottom seal
|_ Different electrical solutions
|_ Electrification possible horizontally and vertically
|_ Guide modules in matching design
THE SLIDING DOOR FOR WALL qi1.
|_ Sliding door with anthracite grey colored bar handle, optional with closing mechanism
|_ Glass thickness for glass doors 10mm
|_ The sliding door can as an option be placed in glass or on the wall
|_ Option: softstop. The sliding door brakes softly, and draws itself back to the zero-position
|_ The sliding door runs on steel balls, revisable
|_ The glass can individually be provided with foil or print
THE MODULAR WALL qi3 | DESIGN: JOHANNES SCHERR.
The quint-it modular wall qi3 is a modular room partition system. Different modules and design elements can be inserted into the individual wall compartments. The wall becomes a flexible and useful structural element in the room with an infinite variety of designs. The profiles in anthracite gray and the high-quality materials of the modules underline the objectivity of the architecture.
The profiles in anthracite-grey and the high-quality materials of the modules underline the objectivity of the architecture.
THE MODULAR WALL qi3 | MODULES.
|_ Variable design of the wall compartments for flexible working environments
|_ Construction: System compatible with the wall qi1
|_ Glass: clear glass, translucent, opaque, structured glass, colored glass
|_ Options: acoustic element, glass- wood- fabric- cork element
|_ Modules: media module, shelf module, whiteboard, moss and nature modules
|_ Position of the modules symmetrical and asymmetrical freely selectable
|_ Frame door with flush lock case in anthracite gray
|_ Tolerance acceptance as standard (glass partition system) +/- 9 mm
|_ Various electrification solutions
THE MODULAR WALL qi3 | GRID.
|_ Position of the profiles symmetrical and asymmetrical freely selectable
|_ Glass: clear glass, translucent, opaque, structured glass, colored glass
|_ Glazing levels and profile levels each flush on all levels
|_ Glass thickness 12mm ESG or VSG
|_ Sound insulation with 12mm VSG Si glass 40 dB in the glass
THE WALL ORGANISATION qi5 | DESIGN: BEATE WILD.
Like the Shaker Peg Rail, office tools can be hung wherever glass systems or closed walls have rails. In times of digital media, the directness of analogue common development of topics becomes increasingly important again in creative processes.
The simplicity of the elements to be arranged provides the basis for personalisation.
THE WALL ORGANISATION qi5 | DETAILS.
|_ Communication, flexibility, acoustic, individuality
|_ Mobile solution in the meeting room and a acoustically effective privacy screen
|_ The wall organisation can as an option be placed in glass or on the wall
|_ Option: Writing board, absorber, magnetic board, magnetic rail, shelf, roll holder, hook
|_ Rail in matching design in anthrazit-grey
|_ Rail fulfills the requirement for labeling requirements for glass walls
|_ As with the Shaker Peg Rail, the rail can be used for hanging office tools anywhere
THE quint-it ABSORBER AND ACOUSTIC PICTURES.
The acoustic fabric absorbers with aluminum frames and acoustic fleece meet sound absorber class A and allow free room design with individually printable surfaces.
THE CUSTOMIZED ABSORBER SYSTEMS AND ACOUSTIC PICTURES.
|_ Acoustic fabric absorbers with aluminium frames and recyclable acoustic fleece
|_ Age-resistant polyester fibre
|_ No airborne fibres, formaldehyde-free, no chemical binders
|_ Non-allergenic, does not contain outgassing substances
|_ Flame retardant B - s1,d0 in accordance with EN 13501
|_ Non-combustible A2 - s1,d0 in accordance with DIN EN 13501
|_ Sound absorption class a in accordance with DIN EN ISO 11654
|_ Fabric cover washable at up to 30 degrees Celsius
|_ Replaceable fabric cover can be imprinted individually
|_ Available in customised sizes
|_ Absorber systems for ceiling and wall mounting
|_ Reversible glass fittings with adhesive mounting points
|_ Powder-coated metal absorbers in RAL and NCS colours
|_ 100% recyclable
|_ Original structure can be rendered to absorbers’ surface for listed buildings
|_ Can be fitted with LED illumination
|_ Easy planning with the Acoustics Calculator
THE quint-it FREE SPACE qiX.
qiX does not need a ceiling connection. In the case of ceilings that are too high and not load-bearing, the connection is made via the load-bearing wall or your own post. The Free space qiX can also be placed in the middle of the room.
|_ Abandonment of ventilation systems and artificial room climate
|_ Use of existing room lighting
|_ qiX can be combined with qi1, qi3 and qi5
|_ Use in listed buildings
|_ Use with non-load-bearing ceilings or roof constructions
|_ Simple and fast planning
THE quint-it DEUTSCHLAND GMBH.
quint-it stands for striving for perfection and joy in good design. The company is developing, producing and selling an innovative full glass system with a clear focus on a contemporary expression. The experienced founders Oliver Betz and Ralf Hausner started the company in 2012.
The idea behind quint-it is to create structure in the room. Current trend studies show us that there is a growing need for multifunctional and flexible rooms. quint-it offers style and value with it´s clear lines and the consistent flushed design.
Less is more.
The profiles let room transitions be the creating element of the architecture in the room. They are orientated to the need for space, acoustic, light and efficient use of the room. The wall system gives individual room for withdrawal, transparency and openness in the office or private home.
To reflect responsible corporate management in our daily activities two factors are essential: knowledge of working conditions and knowledge of flexible spaces.
Knowledge of sustainability and our environment obliges us to take on a conscious attitude to life and responsibility for our living space. You can read more about this in our environmental report.
THE SOCIAL COMMITMENT
quint-it shows social commitment and works with the Caritaswerkstätten St. Georg for people with disabilities in Freiburg. The Caritaswerkstätten have been reliable partners for us in the pre-production for many years. Our orders are executed in high quality and just in time.
Project handling with experience.
This is what we and our partners stand for. In cooperation with the partners, tailor-made solutions are designed and implemented with the necessary flexibility according to the requirements of the customer and builder, the conditions of the building on site and the planned functions.
DAS NETZWERK, WIESBADEN
Two considerations on structure, acoustics and daylight
1. With the modular wall qi3 from quint-it, generous open office areas are structured and space is created for different work situations from individual work, teamwork, to meeting and presentation rooms.
2. Acoustically effective surfaces in the room are created with full fabric covering. The opaque wall parts serve as absorbers and privacy screens, even for confidential conversations.
PROJECT e-g-n ARCHITEKTEN, DARMSTADT
Two reflections on open space
1. More than just a shared job. An office space with flexible communication.
2. The glass partition walls and the wall organization enable the 5 values for flexible work: openness, collaboration, sustainability, community and accessibility.
PROJECT X-QUADRAT PLANUNGSBÜRO, GELNHAUSEN
Two considerations for presenting
1. More than just a partition. The qi3 offers a platform for active and flexible communication.
2. The glass partition walls and the wall organization result in a large number of cross-system combinations.
PROJECT APOPROJEKT, STUTTGART
Two thoughts on the industrial look
1. More than just a trend wall. The style is based on the factory halls of early industrialization.
2. The industrial style sets accents in historic factory and office buildings and as a concept in the big city loft.
PROJECT INSURANCE, COLOGNE
Two reflections on workplace culture
1. The fabric cover is printable, and can thus not only be used as a reflecting surface, but also for emotional, eye-catching presentations.
2. The full glass walls enable light, transparent rooms in which daylight also penetrates walls facing away from windows.
PROJECT LUWIN REAL ESTATE, FRANKFURT AM MAIN
Two reflections on Privacy
1. Temporary acoustic and optical shielding enable concentrated work.
2. The room also gets a homely character trough the curtains.
PROJECT HAFENAMT RHEINAUHAFEN, KÖLN
Two reflections on the modern office
1. The Hafenamt, the old port authority building in Cologne, was built in 1889 and is among the most beautiful buildings in the city. It has been rebuilt and renovated by the architect Michael Zimmermann. The row of open communicating offices in the adjoining new construction runs around the glass-roofed atrium, and creates an unique setting for single- and team offices, and for open space areas. The common conference rooms are on the ground floor. This creates space for withdrawal, but also the opportunity for exchange with guests and clients.
2. Glazed sliding doors invite to open communication inside the building. In this way the employees become a part of this very special ”market place” atmosphere, completely in accordance with the modern office.
PROJECT INDUSTRY ASSOCIATION, DÜSSELDORF
Two reflections on contemporary design
1. The interaction between elements and functions creates a clear modern architecture.
2. The powder-coated aluminum profile is easy to clean. Large glass surfaces and the profile are a clear statement to transparency and cleanliness.
PROJECT SDM STEFAN DARBRUCK MANAGEMENT, FRANKFURT AM MAIN
Two considerations for room design
1. Foiling creates atmosphere and divides the space into zones for openness and privacy. A total work of art is created.
2. The powder-coated aluminum profile and the generous glass surfaces underline transparency and positioning. Less is more.
PROJECT LIVING SPACE, PRIVATE ESTATE
Two reflections on living space and space sufficiency
1. The interior design of our living space has a direct influence on our well-being, as we constantly move, work and live within it.
2. Well-thought-out planning beforehand, with sufficient space for the different usage requirements, can save large future costs for individual building adjustments.
PROJECT 3ST AGENTUR, MAINZ
Two reflections to high-value design of representative office space
1. Generous areas of glass bring daylight and openness to the room.
2. Anthracite grey gives structure to the room and highlights colored and wooden surfaces.
PROJECT INTERFACE, MIES VAN DER ROHE BUSINESS PARK, KREFELD
Three reflections to the planning of large open rooms
1. Large glass walls can be decorated through foiling. Rooms with changing functions can so be divided and still have a high flexibility of use. Individual space for withdrawal, transparency and openness.
2. The revolving doors can also be given their own guide system as an option.
3. The window frames on the outside facade harmonise with the space division system inside the building.
For more projects and impressions see IMAGES
Contact us. We would be glad to help you – from the technical preparation right up to delivery.
You can also order the following documents and data:
|_ Technical documentaion (pdf, dwg)
|_ Assembly instructions (pdf)
|_ Texts for invitation to tender / system description (doc)
|_ Product images (jpg)
|_ Environmental Brochure on Sustainability (pdf)
|_ Environmental certificates for the product groups (pdf)
|_ CE certification (pdf)
